Button Belt T10 3040
Belt Dimensions 1. 304 Teeth
2. T10 (10MM) Pitch,
3. 3040 MM Pitch Length
4. 25MM Belt width
5. 84 Buttons on top side
HL Timing Belts
HL Timing Belts
Belt Dimensions
1. Pitch 9.525MM
2. Tooth H Type
3. SizesL 322 HL, 367 HL, 694 HL, 821 HL
Reiter C60 Belts
Reiter C60 Belts
Belt Dimensions 1. 291 Teeth
2. AT 10 Pitch (10MM)
3. 2910 MM Length
4. 25MM Belt Width
5. Top Side Studds as per image
6. PART NO. / CAT. NO. 10034747
Reiter Card Belts-1
Reiter Card Belts-1
Belt Dimensions 1. 3806.4MM Pitch Length
2. 25MM Belt Width
3. 104 Arc Profiles at one side
4. Colour - Blue
Reiter Card Belts-2
Reiter Card Belts-2
Belt Dimensions 1. 3806.4MM Pitch Length
2. 25MM Belt Width
3. 104 Arc Profiles at one side
4. 104 Flat Profiles on other side
5. Part No. 0245 – 2811, Cat. No. 014.056
6. Colour - Green
Spinning Ring Frame
Spinning Ring Frame Belts
Belt Dimensions 1. 1745 VY 62 28
2. 1810 VY 70 30
Variable Speed Belts
Variable Speed Belts
We require the following dimensions: 1. Out side Circumferance (OC) of belt.
2. Total Belt thickness (T).
3. Belt top width (W).
4. Belt Angle (if available) (A)
Our Production Range :
1. OC : 508mm – 1975mm
2. (T) : 6mm – 18mm
3. (W) : 13mm – 125mm
4. (A) : As per customer requirement.
